Item: QXSS-08075CB011
Rated current: 13.5A
Max speed: 3500rpm
Motor length: 145.5mm
Product Description
ADTECH QXSS Series Servo Motor List | ||||
Model | QXSS-08075CA011 | QXSS-08075CA111 | QXSS-08075CB011 | QXSS-08075CB111 |
Matching Driver | QXMP06NA-B | |||
Flange(mm) | 80 | |||
Rated Power(kw) | 0.75 | |||
Rated Torque(Nm) | 3.5 | |||
Maximum Torque(Nm) | 9.5 | |||
Rated current(A) | 5 | |||
Max current(A) | 13.5 | |||
Rated speed(r/min) | 2000 | |||
Max speed ( r/min) | 3500 | |||
Inertia(kgm2 x 10-4) | 1.2 | |||
Rated Voltage(V) | 220 | |||
Coder | 24 multi bit | 17 single bit | ||
Dia. Of Axis(mm) | 19 | |||
Motor Length(mm) | 145.5 | 186.5 | 145.5 | 186.5 |
Axis Length(mm) | ||||
With Brake | × | √ | × | √ |
