Bus Type Motion Control Card

ADT6329E EtherCAT bus control card, supports up to 64 nodes, has the function of motion trajectory pre-processing planning, supports four groups of independent pre-processing interpolation channels, supports up to 32 axis interpolation, a variety of acceleration and deceleration control, space arc interpolation, logical position variable loop, virtual gantry synchronization, physical axis mapping, Electronic CAM, 2-3 dimensional position comparison, high-speed flybat support 8 encoder feedback input, the maximum receiving frequency of 4MHz.

Send Inquiry

● Support up to 64 nodes: EtherCAT bus servo (stepping) control, bus IO module expansion

● Communication cycle: 250us-4ms

● With motion trajectory pre-processing planning function, support four groups of independent pre-processing interpolation channels

● Support QXE, EM, Panasonic, Sanyo and other EtherCAT protocol communication servo (stepper) or other EtherCAT communication extension modules

● Supports up to 32 axis interpolation

● A variety of acceleration and deceleration control, space arc interpolation, logical position variable ring, virtual gantry synchronization, physical axis mapping, electronic CAM, 2-3 dimensional position comparison, high-speed fly shot

● Support 8 encoder feedback input, maximum receiving frequency 4MHz

Bus type motion control card 1
