Features &Function
1. GH-CNC50 universal spring machine with cam. The mechanic parts contain eight sets of slide, crank and cam rotation axis. The cam axis control by a 5.5kw Japan brand servo motor
2. GH-CNC50 control by CNC controller, the controller made by ADTECH, Can have the best price and service. Easy for adjusting the parameters in controller and can set the spring with less time
3. GH-CNC50 wire feeder control by 7kw servo motor, can produce more smooth and faster.
4. Optional Accessories: wearing parts. The 4th axis(rolling axis), safety door
Specification
Model: GH-CNC50
Wire Diameter(mm): 2.0-5.0
Axis: 3
Maximum Feeding Length(mm): Unlimited
Maximum Manufacture speed(pcs/min): 60
Cam Servo Motor（kw）: 5.5
Wire Feed Servo Motor(kw): 7
Z Axis Servo Motor(kw): 1.5
Power AC: Three phase, 380V
Dimensions(mm): L-1800*W-1300*H-2100
Machine Weight(kg): 3500
